170-Point Breadboard MB-170
Breadboard 170 points.
This breadboard 170 points will allow you to produce a rapid and repeated prototyping electronic circuits without soldering, at the same time, maintaining accuracy, reliability and ease of debugging. Grooves in the side to link up with several development boards, increasing the area placed circuitry. To breadboard bottom attached double-sided tape that will give you the opportunity to stick it securely to any smooth surface.
In this breadboard has many holes, electrically interconnected by metal strips. Conclusions radio components and chips are inserted into these holes, and then connect the conductors or jumpers (pieces stripped wires). Long rows of contacts on the top and bottom of the board - the power bus, they are used to connect multiple points of the scheme with the power source and "earth". Hole spacing is 2.54 mm, which is the standard distance between the conclusions of the majority of transistors and ICs in DIP-packages, as resistors, capacitors and other radio components typically have long flexible conclusions that can be installed anywhere.
- Number of points:
- 2.54 mm
